Telecentric Lens
MML014-HR110D-5M
▪ Highest image quality of the MML Series designed for use with 5 megapixel, 3.45 μm element sensors
▪ WD 110 mm lineup focuses on large FOV applications with magnification of 0.14× and 0.3×(magnification depends on model)
▪ All models include uniform coaxial illumination functionality option
▪ Features an internal reflection light-scattering design and noise reduction filter for hot spot reduction
▪ Very low distortion
Download DataTechnical DatasheetDrawing DataDrawing Data（STEP）
Main Applications
High accuracy alignment and OCR/OCV
Surface inspection such as silicon wafers and machine components
Metrology and gauging
Main Applications
Specifications
|
Spec |
MML014-HR110D-5M |
|
Coaxial Illumination |
- |
|
Magnification |
0.14±5% |
|
WD (mm) |
110 |
|
Resolution (μm) |
19.2 |
|
Depth of Field (mm) |
16.4 |
|
NA |
0.018 |
|
Effective Fno |
4 |
|
Distortion (%) |
0.001 |
|
Weight (g) |
730 |
|
Largest Compatible Sensor |
2/3" |
|
Mount |
C Mount |
* Resolution values indicate the theoretical resolution at a wavelength of 550nm
* Depth of field is calculated assuming a horizontal 240TV resolution using a 1/2 CCD camera. (Permissible circle of confusion on the image-formation side: 40μm)
External View
